19MM CALIBRATED BWP
IS 710 CERTIFIED
IS 710 CERTIFIEDNeed Joinery Span Guidance?
Unsure whether 16mm or 19mm is required for kitchen carcass vs wardrobe sliding shutters? Our wood engineers will audit your carpentry drawings.
Submit Enquiry →IS 710 BWP Marine Hardwood Plywood (19mm)
Offers & Procurement Benchmarks
✓
Live Verified Rate: ₹118 / Sq Ft (19mm Calibrated) · Direct Mill Benchmark.
✓
Zero-Core-Gap Assurance: Composed with 100% full hardwood core veneers and cross-banded layup to eliminate internal air voids.
✓
72-Hour Boiling Water Proof: 100% unextended Phenol Formaldehyde (PF) synthetic resin adhesive ensuring zero delamination in high moisture kitchens.
🚚Direct Truck DispatchSite dispatch in 24–48 hrs
🛡️72-Hour Boiling ProofIS 1734 Part 6 Certified
⚖️4-Side Calibrated±0.1 mm uniform thickness
Technical Specifications
| Product Grade | Boiling Water Proof (BWP) Marine Hardwood |
|---|---|
| Standard Compliance | IS 710 : 2010 (Marine Plywood Specification) |
| Adhesive Resin System | 100% Unextended Phenol Formaldehyde (PF) Resin |
| Sheet Thickness Metric | 19 MM (Tolerance ±0.1 MM) |
| Boiling Water Resistance | Passes > 72 Hours continuous boiling without glue-line failure |
| Moisture Content | 8 – 12% (Kiln seasoned & conditioned) |
| Screw Holding Strength | > 280 KGF (Parallel to surface) · > 220 KGF (Perpendicular) |
| Anti-Borer & Termite | Glue Line Poisoning (GLP) with organophosphorus preservative |
Shipped by Ostaad Verified LogisticsSold by Direct Primary Mill Network
TRANSPARENT PROCUREMENT BENCHMARK
₹118
/ SQ FT (19MM) · TAX INCLUSIVE
How does Ostaad Bulk Buying work?
1
Calculate Joinery Spans: Input shelf span and thickness in our Load Deflection Simulator.
2
Transparent Rate: Direct mill quote per sheet with zero retail middleman markup.
3
Site Delivery: Insured flat-bed transport with caliper gauge thickness inspection.
STRUCTURAL JOINERY BENCHMARK
Shelf Span & Load Deflection Simulator
Simulate how shelf thickness and span length impact bending deflection under heavy utensil or book loads to specify correct carcass spans.
Joinery Parameters
DEFLECTION ANALYSIS
31.5 mm Deflection
STRUCTURAL STATUS: EXCESSIVE SAG (Add a center vertical stiffener or upgrade thickness).
RECOMMENDED SPAN
Max 40"
MODULUS (MOE)
7,800 N/mm²
BOND STRENGTH
Pass 72h Boil
RESIN ADHESION BENCHMARK
Boiling Water Delamination Endurance (Hours)
Tested per IS 1734 Part 6: Boiling Water Resistance test measuring hours before synthetic resin delaminates or separates plies.
Bonded exclusively with unextended phenol formaldehyde resin: zero core gaps and zero veneer separation even in sunken under-sink cabinet environments.TEST BENCHMARK: IS 710 : 2010 COMPLIANT
BIS BENCHMARK MATRIX
Plywood Specification Compliance (IS 710 vs IS 303)
Bureau of Indian Standards parameter comparison for Marine Grade (IS 710), Boiling Water Resistant (IS 303 BWR), and Commercial Moisture Resistant (IS 303 MR).
| TECHNICAL PARAMETER | IS 710 BWP MARINE | IS 303 BWR GRADE | IS 303 MR COMMERCIAL | TEST PROCEDURE |
|---|---|---|---|---|
| Boiling Water Test | Pass 72 Hours Boiling | Pass 8 Hours Boiling | Fails under 15 minutes | IS 1734 (Part 6) |
| Adhesive Type | Unextended Phenolic (PF) | Fortified Melamine Urea | Urea Formaldehyde (UF) | Chemical Analysis |
| Mycological Resistance | Resistant to wood rot / fungi | Moderate Resistance | Vulnerable in damp zones | IS 1734 (Part 7) |
| Screw Holding Force | > 280 KGF (Face) / > 220 KGF (Edge) | > 200 KGF (Face) | > 150 KGF (Face) | IS 1734 (Part 11) |
| Ideal Joinery Application | Kitchen Carcasses, Vanities, Roof Decks | Bedroom Wardrobes & Paneling | Dry Living Furniture Only | Application Audit |
← Swipe horizontally to view full matrix →
